4 POST CAR PARKING LIFT
TILTING CAR PARKING LIFT
Parameter:
If the ceiling height of your parking space is not sufficient,
all you need to do is to try tilting the vehicle on top to fit in.
It has never been so easy to expand the most limited parking space until
the tilting parking lift, even in a place with restricted height. This type allows you to
make the most of your low-ceiling garage by parking 2 sedans on top of each other.
Adjustable platform angle & stopping height make it flexible with various sedans at different ceiling heights.
Inquiry Now
- Product Details
- Specifications
- Inquiry Now
- Related Products
Product Details
Model | TTP20 |
Lifting capacity | 2000kg |
Cylinder NO. | TWO |
Lifting height | 2000 mm |
Runway Width | 1952 mm |
Operation system | Cylinder with carriage,push button controls |
Lock release | Electromagnetic lock release |
HPU/Voltage | 3kw 110/220v-380v, 50/60hz , 1/3ph |
Safety protection device:
Fall-proof device: stop running after the platform has risen to a certain height, start the fall-proof device to prevent the platform from falling suddenly.
Limit switch: Limit the rising height of the platform, to prevent it from exceeding the maximum safe height when it rises.
Emergency switch: When the equipment is limited and abnormal, the power supply can be cut off by pressing the emergency stop switch.
Specifications
Features:
Ø It can be used to park sedans.
Ø Wide use, simple installation and easy operation.
Ø Lifting height can be adjust from 1500mm to 1700m.
Ø Infrared Photoelectric Detection System, make sure the equipment running safe.
Ø Automatic locking device ensures more safety and reliability of parking.
Ø Two-stage inverted hydraulic cylinder lifting adopts Italian imported sealing ring, which has good quality
and no oil leakage, making the equipment run more stable.
Ø DC24V control voltage to ensure the safety of operators.
Ø Space height need at least 3300mm, suitable some low ceiling place to use.
Ø Have CE certification, through 115% dynamic load and 150% static load field testing
Ø It can be equipped with remote control, which makes the operation more convenient.
FAQ:
Q1: What are your terms of payment?
A: T/T 50% as deposit, and 50% before delivery.
We'll show you the photos of the products and packages before you pay the balance.
Q2. What are your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q3. How about your delivery time?
A: Generally, it will take 25 to 40 days after receiving your advance payment.
The specific delivery time depends on the items and the quantity of your order.
